RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, schwarz




Preise nur für eingeloggte Nutzer sichtbar
RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 0,5m, schwarz
Artikelnummer:
K5456.0,5
EAN Nr.:
4049759030162
Produktinformationen für RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 0,5m, schwarz
Das Cat.5e RJ45 Patchkabel gewährleistet gute Eigenschaften für 2,5 Gigabit Ethernet Anwendungen. Durch die doppelte Abschirmung ist das Patchkabel noch besser gegen EMV Strahlung abgesichert.
Querschnitt 4 x 2 x AWG26/7
Gegossene Knickschutztülle (patentiert)
Kabelaufbau SF/UTP
Längenaufdruck auf der Tülle
Leitermaterial CCA
Querschnitt 4 x 2 x AWG26/7
Gegossene Knickschutztülle (patentiert)
Kabelaufbau SF/UTP
Längenaufdruck auf der Tülle
Leitermaterial CCA
Technische Eigenschaften
Ausführung: | Geschirmt |
---|---|
Steckverbindertyp Anschluss 1: | RJ45 8(8) |
Steckverbindertyp Anschluss 2: | RJ45 8(8) |
Kategorie: | 5e |
Mantel-Farbe: | schwarz |
AWG-Querschnitt: | 26/7 |
Ausführung flammwidrig: | Nein |
Außendurchmesser des Kabels: | 5,7 mm |
Bandbreite: | 100MHz |
Belegung: | nach TIA/EIA 568B |
Betriebs-/Bemessungsspannung: | max. 50 V DC |
Biegeradius: | >25 mm |
Einsatzgebiet: |
Industrial Ethernet Rechenzentrum Strukturierte Gebäudeverkabelung |
Farbe der Knickschutztülle: | schwarz |
Geeignet für Schutzart (IP): | IP20 |
Gesamtabschirmung: | 65 % |
Halogenfrei: | Nein |
Isolationswiderstand: | 10 MΩ |
Kabelaufdruck: | SFTP 300 CAT.5E 26AWGX4P PATCH ISO/IEC 11801 & EN 50173 VERIFIED |
Kabelkonstruktion: | 4x2 |
Kabeltyp: | SF/UTP |
Knickschutztülle: | angespritzt |
Kontakte: | Vergoldet µ" Vergoldet |
Kontaktwiderstand: | 30 mΩ |
Leitermaterial: | CCA |
Leiterwiderstand DC: | 146 Ω/km |
Längenaufdruck: | Ja |
Mantelmaterial: | Polyvinylchlorid (PVC) |
POE Klasse: |
4PPoE nach IEEE802.3bt PoE+ nach IEEE802.3at PoE nach IEEE802.3af |
Pinbelegung: | 1:1 |
Prüfspannung: | 1000 (V DC, 1min) Ader/Ader und Ader/Schirm |
Rasthebelschutz: | Ja |
Schirmkontaktierung: | Punktueller Schirmkontakt |
Schleifenwiderstand: | 292 Ω/km |
Silikonfrei: | Ja |
Steckertyp: | RJ45 Standard |
Steckverbinder: | IEC 60603-7-3 |
Steckzyklen: | ≥750 |
Strombelastbarkeit: | max. 1 A |
Temperaturbereich: | -5 – 70 °C |
Widerstandsunsymmetrie: | 5 % |
Ölbeständig nach EN 60811-2-1: | Nein |
Ölbeständig nach EN 60811-404: | Nein |
Übertragung: | 2,5Gbit |
Varianten
Art. Nr. | Bezeichnung | Länge | Längentoleranz | |
---|---|---|---|---|
K5456.0,5 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 0,5m, schwarz | 0,5 m | ±5 % | |
K5456.1 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 1m, schwarz | 1,0 m | ±5 % | |
K5456.1,5 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 1,5m, schwarz | 1,5 m | ±5 % | |
K5456.2 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 2m, schwarz | 2,0 m | ±5 % | |
K5456.3 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 3m, schwarz | 3,0 m | ±5 % | |
K5456.5 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 5m, schwarz | 5,0 m | ±5 % | |
K5456.7,5 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 7,5m, schwarz | 7,5 m | ±5 % | |
K5456.10 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 10m, schwarz | 10,0 m | ±5 % | |
K5456.15 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 15m, schwarz | 15,0 m | ±5 % | |
K5456.20 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 20m, schwarz | 20,0 m | ±5 % | |
K5456.25 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 25m, schwarz | 25,0 m | ±5 % | |
K5456.30 | RJ45 Patchkabel SF/UTP, Cat.5e, PVC, CCA, 30m, schwarz | 30,0 m | ±5 % |
