Industrial Gigabit PoE DIN rail injector
Industrial Gigabit PoE DIN rail injector 802.3at, PoE+ 36 W, 12–56 V DC
Item number:
IGP-0102
EAN no.:
4015867196595
Product information for Industrial Gigabit PoE DIN rail injector 802.3at, PoE+ 36 W, 12–56 V DC
No additional power line to the end device is required
Provides power and data to PoE-PD devices via a single Ethernet cable
Remote power supply up to 100 m
Unique locking feature for easy installation
Total PoE power budget: 36W
The LevelOne IGP-0102 is a Power over Ethernet (PoE) injector that not only provides a cost-effective solution for power distribution, but also provides a seamless way to integrate Powered Devices (PDs) into the existing LAN infrastructure in busy environments environment to use.
In addition, non-PoE devices such as wireless access points can also be powered remotely by adding additional PoE splitters. The devices can therefore be used in areas that are difficult to access, such as: B. on the ceiling, where there are no sockets or power lines nearby.
General
Color: Black
Miscellaneous
Data rate Gigabit Ethernet
Grade industrial
Others
Operating humidity 5% RH ~ 95% RH
Operating temperature -40°C ~ 75°C
Physical Specifications
Dimensions (W x D x H) 103.5 x 32 x 81.5 mm
Product weight (kg) 0.15
System specifications
Data rate 10/100/1000 Mbps
Indicator Power x 2
Fashion x 2
Fastening DIN rail mount
Pin assignment and polarity 1/2 (+), 3/6 (-)
Port Configuration 2* 10/100/1000 Mbps,
Energy consumption <5W
Standards IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE802.3af for POE
IEEE802.3at for POE+
Provides power and data to PoE-PD devices via a single Ethernet cable
Remote power supply up to 100 m
Unique locking feature for easy installation
Total PoE power budget: 36W
The LevelOne IGP-0102 is a Power over Ethernet (PoE) injector that not only provides a cost-effective solution for power distribution, but also provides a seamless way to integrate Powered Devices (PDs) into the existing LAN infrastructure in busy environments environment to use.
In addition, non-PoE devices such as wireless access points can also be powered remotely by adding additional PoE splitters. The devices can therefore be used in areas that are difficult to access, such as: B. on the ceiling, where there are no sockets or power lines nearby.
General
Color: Black
Miscellaneous
Data rate Gigabit Ethernet
Grade industrial
Others
Operating humidity 5% RH ~ 95% RH
Operating temperature -40°C ~ 75°C
Physical Specifications
Dimensions (W x D x H) 103.5 x 32 x 81.5 mm
Product weight (kg) 0.15
System specifications
Data rate 10/100/1000 Mbps
Indicator Power x 2
Fashion x 2
Fastening DIN rail mount
Pin assignment and polarity 1/2 (+), 3/6 (-)
Port Configuration 2* 10/100/1000 Mbps,
Energy consumption <5W
Standards IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE802.3af for POE
IEEE802.3at for POE+
Technical properties
| Gigabit Ethernet: | True |
|---|---|
| Manufacturer: | LevelOne |
| Mounting method: | DIN rail (top hat rail) |
| Power over Ethernet (PoE): | 802.3 at (PoE+) |
Safety instructions
Warning: Danger of electric shocks and short circuits! Ensure proper earthing to avoid electric shocks. Avoid overloading as this can lead to overheating and short circuits. Check that the housing is undamaged and that there are no exposed contacts or bare wires. Ensure that all electrical connections are made correctly and that the ambient conditions comply with the technical specifications. Always keep a sufficient distance from live devices and avoid misuse.
