EFB 1.25G SFP SM 1310nm FP 20KM LC DDM, compatible HP Aruba J4859D
Product information for EFB 1.25G SFP SM 1310nm FP 20KM LC DDM, compatible to HP Aruba J4859D
Technical data
SFP transceiver with LC duplex connector
Hot-pluggable SFP
With digital diagnostic monitoring function
1310nm Fabry-Perot Laser Sender
Up to 20km with 9/125µm SM fiber
Low EMI and excellent ESD protection
Temperature range 0 -/+ 70°C
RoHS conform
Application
1.25Gbit/s 1000Base-LX Ethernet
1.06Gb/s Fiber Channel
| Compatible to: | HP Enterprise |
|---|---|
| Connector: | LC Duplex |
| Detecting range: | 20 km |
| Medium: | Singlemode |
| Protocol: | 1000BaseLX |
| Speed: | 1000 Mbit/s |
| Temperature: | 0 – 70 °C |
| Wave length: | 1310 nm |
Technical properties
| Compatible to: | HP Enterprise |
|---|---|
| Connector: | LC Duplex |
| Detecting range: | 20 km |
| Medium: | Singlemode |
| Protocol: | 1000BaseLX |
| Speed: | 1000 Mbit/s |
| Temperature: | 0 – 70 °C |
| Wave length: | 1310 nm |
Product information for EFB 1.25G SFP SM 1310nm FP 20KM LC DDM, compatible to HP Aruba J4859D
Technical data
SFP transceiver with LC duplex connector
Hot-pluggable SFP
With digital diagnostic monitoring function
1310nm Fabry-Perot Laser Sender
Up to 20km with 9/125µm SM fiber
Low EMI and excellent ESD protection
Temperature range 0 -/+ 70°C
RoHS conform
Application
1.25Gbit/s 1000Base-LX Ethernet
1.06Gb/s Fiber Channel
| Compatible to: | HP Enterprise |
|---|---|
| Connector: | LC Duplex |
| Detecting range: | 20 km |
| Medium: | Singlemode |
| Protocol: | 1000BaseLX |
| Speed: | 1000 Mbit/s |
| Temperature: | 0 – 70 °C |
| Wave length: | 1310 nm |
| Compatible to: | HP Enterprise |
|---|---|
| Connector: | LC Duplex |
| Detecting range: | 20 km |
| Medium: | Singlemode |
| Protocol: | 1000BaseLX |
| Speed: | 1000 Mbit/s |
| Temperature: | 0 – 70 °C |
| Wave length: | 1310 nm |
Safety instructions
Warning: Danger of electric shocks and short circuits! Ensure proper earthing to avoid electric shocks. Avoid overloading as this can lead to overheating and short circuits. Check that the housing is undamaged and that there are no exposed contacts or bare wires. Ensure that all electrical connections are made correctly and that the ambient conditions comply with the technical specifications. Always keep a sufficient distance from live devices and avoid misuse. Warning: Laser beams! Open laser beams, especially in the visible, UV or infrared range, pose a significant safety risk. Direct or indirect exposure to laser beams can lead to serious eye injuries, skin damage and other health problems. Eye exposure is particularly dangerous as it can cause permanent damage such as retinal damage or blindness. Avoid direct eye contact and do not look directly into the laser light.
