EFB 10G SFP+ MMF,300m 850nm LC DDM, compatible to Cisco SFP+-10G-SR
EFB 10G SFP+ MMF,300m 850nm LC DDM, compatible to Cisco SFP+-10G-SR
Item number:
SFP10GSR-300M
EAN no.:
4049759255480
Product information for EFB 10G SFP+ MMF,300m 850nm LC DDM, compatible to Cisco SFP+-10G-SR
10G SFP + transceiver for multimode 10G data transmission in fiber optic networks. Compatible with Cisco SFP +/-10G-SR and standard MSA SFP + ports
Technical data
SFP + transceiver with LC duplex connection
Hot-pluggable SFP
With digital diagnostic monitoring function
850nm VCSEL laser
LC duplex connection
Up to 300m on 50/125µm multimode fiber
Low EMC interference and good ESD protection
Temperature range 0 to +70°C
RoHS compliant
Compatible with SFF8472
Application area
10G Ethernet
Fiber Channel
Technical data
SFP + transceiver with LC duplex connection
Hot-pluggable SFP
With digital diagnostic monitoring function
850nm VCSEL laser
LC duplex connection
Up to 300m on 50/125µm multimode fiber
Low EMC interference and good ESD protection
Temperature range 0 to +70°C
RoHS compliant
Compatible with SFF8472
Application area
10G Ethernet
Fiber Channel
Technical properties
| Compatible to: | Cisco and Standard |
|---|---|
| Connector: | LC Duplex |
| Detecting range: | 82/300 m |
| Medium: | Multimode |
| Protocol: | 10GBaseSR |
| Speed: | 10 Gbit/s |
| Wave length: | 850 nm |
Safety instructions
Warning: Danger of electric shocks and short circuits! Ensure proper earthing to avoid electric shocks. Avoid overloading as this can lead to overheating and short circuits. Check that the housing is undamaged and that there are no exposed contacts or bare wires. Ensure that all electrical connections are made correctly and that the ambient conditions comply with the technical specifications. Always keep a sufficient distance from live devices and avoid misuse.
