Fast Ethernet PoE Splitter 15.4W
Fast Ethernet PoE Splitter 15.4W
Item number:
POS-1002
EAN no.:
4015867160701
Product information for Fast Ethernet PoE Splitter 15.4W
1 Fast Ethernet Port
DATA + PoE IN up to 15.4 W
Fast Ethernet DATA OUT and 1 x POWER OUT (5 V, 9 V, 12 V DC)
IEEE-802.3af PoE compatible
Diagnostic LEDs
Dip switch for output voltage 5 V, 9 V or 12 V
Plastic housing fanless (L x W x H): 80 x 55 x 31 mm
DATA + PoE IN up to 15.4 W
Fast Ethernet DATA OUT and 1 x POWER OUT (5 V, 9 V, 12 V DC)
IEEE-802.3af PoE compatible
Diagnostic LEDs
Dip switch for output voltage 5 V, 9 V or 12 V
Plastic housing fanless (L x W x H): 80 x 55 x 31 mm
Technical properties
| Depth: | 80.0 mm |
|---|---|
| Ethernet: | True |
| Fast Ethernet: | True |
| Height: | 31.0 mm |
| Manufacturer: | LevelOne |
| Mounting method: | other |
| Number of ports 10/100 Mbps RJ45: | 1 |
| Power over Ethernet (PoE): | 802.3 af (PoE) |
| Width: | 55.0 mm |
