INFRALAN® LC Adapter in metal housing
INFRALAN® adapter LC Duplex OS2 metal housing
Item number:
IKL-LCDU-M-SI
EAN no.:
4049759194260
Product information for INFRALAN® adapter LC Duplex OS2 metal housing
The INFRALAN® LC Duplex adapter in metal housing
For SC-Simplex breakouts
Conform to DIN EN 61754-20
High stability due to metal housing and lower sensitivity to temperature fluctuations
Mounting options via clips or M2 threaded screws
For SC-Simplex breakouts
Conform to DIN EN 61754-20
High stability due to metal housing and lower sensitivity to temperature fluctuations
Mounting options via clips or M2 threaded screws
Technical properties
| Accessories: | Metrische Schraube |
|---|---|
| Conform to Standard: | IEC61754-20 |
| Construction type: | SC-Simplex |
| Height: | 9.3 mm |
| Length: | 29,2 mm |
| Material housing: | Metall |
| Material sleeve: | Keramik |
| Operating temperature: | -40 – 85 °C |
| Storage Temperature: | -40 – 85 °C |
| Type of connector connection 1: | LC-Duplex |
| Type of connector connection 2: | LC-Duplex |
| Type of fastening: | Schraube/einrasten |
| Width: | 22,0 mm |
Manufacturer information
EFB-Elektronik GmbH
Striegauer Str. 1
33719 Bielefeld
info@efb-elektronik.de
https://www.efb-elektronik.de
