BlueOptics AOC Fibre Optic Cable, SFP+ to SFP+
BlueOptics, Active Optical Cable, 2 x SFP+, 10GBASE-SR, 1m, MM G50/125μm
Item number:
BO353503J1M-BO
EAN no.:
4063232614700
Product information for BlueOptics, Active Optical Cable, 2 x SFP+, 10GBASE-SR, 1m, MM G50/125μm
For 10G Ethernet Data Center Intra-Rack and Inter-Rack links
Hot-pluggable SFP+ cable ends
Rigid pull-tab for improved high-density installations
Supports 10.3125 Gb/s bit rate
RoHS-6 compliant (lead-free)
SFI limiting interface
Single 3.3V power supply
Low power dissipation
Commercial temperature range: 0° C to 70° C
Hot-pluggable SFP+ cable ends
Rigid pull-tab for improved high-density installations
Supports 10.3125 Gb/s bit rate
RoHS-6 compliant (lead-free)
SFI limiting interface
Single 3.3V power supply
Low power dissipation
Commercial temperature range: 0° C to 70° C
Technical properties
| Compatible to: | Standard |
|---|
Variants
| Item no. | Name | Length | |
|---|---|---|---|
| BO353503J1M-BO | BlueOptics, Active Optical Cable, 2 x SFP+, 10GBASE-SR, 1m, MM G50/125μm | 1.0 m | |
| BO353503J3M-BO | BlueOptics, Active Optical Cable, 2 x SFP+, 10GBASE-SR, 3m, MM G50/125μm | 3.0 m | |
| BO353503J10M-BO | BlueOptics, Active Optical Cable, 2 x SFP+, 10GBASE-SR, 10m, MM G50/125μm | 10.0 m |
Safety instructions
Warning: Danger of electric shocks and short circuits! Ensure proper earthing to avoid electric shocks. Avoid overloading as this can lead to overheating and short circuits. Check that the housing is undamaged and that there are no exposed contacts or bare wires. Ensure that all electrical connections are made correctly and that the ambient conditions comply with the technical specifications. Always keep a sufficient distance from live devices and avoid misuse.
