Item no.	Name	Type of connector external	Color	Pigtail	Suitable for number of couplings/adapters	With number of couplings/adapters	RAL-number	Type of connector interior	Pigtail Coating material	Insertion loss 1625nm	Minimal bendung radius static	Pigtail colour	Pigtail Buffertype	Insertion loss 1550nm	Adapter colour	Pigtail diameter	Minimal bendung radius dynamic	Insertion loss 1310nm	Return loss1625nm	Scope of delivery	Return loss 1310nm	Pigtail length	Pigtail plug colour	Return loss 1550nm
BA71920L12	Splice box gy sliding LC/APC OS2 12x fanout pigtails and 6x duplex adapter	LC-Duplex	grey	12 x LC-APC	12	6	7035	LC-Duplex	LSZH	≤0.25 dB	10xD	DIN	Loose-Buffered	≤0.25 dB	green	0.9 mm	20xD	≤0.25 dB	≥65 dB	19'' splice box extendable with frontpanel and<br>6xadapter, 6xadapter dummy, <br>12xpigtail+Test protocol, 1xsplice cassette+cover+screw, 1xcrimp splice protector holder, 2xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20	≥65 dB	2 m	green	≥65 dB	Select variants
BA71920L24	Splice box gy sliding LC/APC OS2 24x fanout pigtails and 12x duplex adapter	-	grey	24 x LC-APC	12	12	7035	-	LSZH	≤0.25 dB	10xD	DIN	Loose-Buffered	≤0.25 dB	green	0.9 mm	20xD	≤0.25 dB	≥65 dB	19'' splice box extendable with frontpanel and<br>12xadapter, 24xpigtail+Test protocol, 2xsplice cassette+cover+screw, 2xcrimp splice protector holder, 4xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20	≥65 dB	2 m	green	≥65 dB	Select variants
