Splice box gy sliding LC OS2 48x fanout pigtails and 24x duplex adapter
Content:
1 Stück
Splice box gy sliding LC OS2 48x fanout pigtails and 24x duplex adapter
Item number:
BA71921L48
EAN no.:
4049759284565
Product information for Splice box gy sliding LC OS2 48x fanout pigtails and 24x duplex adapter
The pull-out splice box from EFB-Elektronik is designed for the structured pick-up of splices and the clear management of single-mode fibre optic connections in a 19-inch rack. The 1U version combines a compact design with service-friendly access and is designed for OS2 according to ITU-T G.652.D and 9/125.
• Extendable 1U 19" design – Allows for compact integration into the rack and makes it easy to access the splice level for maintenance and expansion.
• Front panel with 24 LC duplex couplings – Ensures a clearly structured, pre-terminated assembly of the single-mode connectors and keeps the rack front uncluttered.
• 48 prepared LC pigtails with LSZH jacket and 2 m length – Support clean splicing organisation and reduce installation effort in the field.
The splice box has a sheet steel housing in grey according to RAL 7035 and is designed for the clean routing of single-mode lines. The LC duplex couplings with ceramic ferrule guide and the LSZH-coated pigtails support use in professional OS2 installations. Pre-assembled crimp/ANT splice holders and enclosed shrink splice holders enable flexible and traceable splice organisation.
Technical details
• Extendable: extendable
• Fibre class: OS2 according to ITU-T G.652.D
• Couplings: LC-Duplex
• With number of couplings/adapters: 24
• Coupling material: plastic
• Pigtail: 48 x LC
• Pigtails prepared: discontinued
• Number of height units (U): 1U
• Alignment of the couplings/adapters: vertical
• Fibre type: Single-mode 9/125
• Couplings (ferrule guide): Ceramic
• Coupling colour: blue
• Material: sheet steel
• Colour: grey
• Pigtail Buffer Type: Loose-Buffered
• Pigtail Coating Material: LSZH
• Pigtail diameter: 0.9 mm
• Pigtail length: 2 m
• Mounting type: 482.6 mm (19 in) Installation
• Extendable 1U 19" design – Allows for compact integration into the rack and makes it easy to access the splice level for maintenance and expansion.
• Front panel with 24 LC duplex couplings – Ensures a clearly structured, pre-terminated assembly of the single-mode connectors and keeps the rack front uncluttered.
• 48 prepared LC pigtails with LSZH jacket and 2 m length – Support clean splicing organisation and reduce installation effort in the field.
The splice box has a sheet steel housing in grey according to RAL 7035 and is designed for the clean routing of single-mode lines. The LC duplex couplings with ceramic ferrule guide and the LSZH-coated pigtails support use in professional OS2 installations. Pre-assembled crimp/ANT splice holders and enclosed shrink splice holders enable flexible and traceable splice organisation.
Technical details
• Extendable: extendable
• Fibre class: OS2 according to ITU-T G.652.D
• Couplings: LC-Duplex
• With number of couplings/adapters: 24
• Coupling material: plastic
• Pigtail: 48 x LC
• Pigtails prepared: discontinued
• Number of height units (U): 1U
• Alignment of the couplings/adapters: vertical
• Fibre type: Single-mode 9/125
• Couplings (ferrule guide): Ceramic
• Coupling colour: blue
• Material: sheet steel
• Colour: grey
• Pigtail Buffer Type: Loose-Buffered
• Pigtail Coating Material: LSZH
• Pigtail diameter: 0.9 mm
• Pigtail length: 2 m
• Mounting type: 482.6 mm (19 in) Installation
| Adapter material: | plastic |
|---|---|
| Adapters: | LC-Duplex |
| Couplings (ferrule guide): | Ceramic |
| Depth: | 243 mm |
| Depth adjustment: | 40 mm |
| Fibre class: | OS2 acc. to ITU-T G.652.D |
| Fibre type: | Single mode 9/125 |
| Height: | 44 mm |
| Material: | Steel sheet |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Packaging: | EFB-Elektronik Carton |
| Pigtails prepared: | stripped |
| Remark: | vertical |
| Sliding: | sliding |
| Splice cassettes (capacity): | 4 |
| Splice cassettes (number): | 1 |
| Splice cassettes (number of splice holders): | 18 x crimp splice protection holder per splice cassette2 x shrink splice protection holder per splice cassette |
| Splice cassettes (splice holder capacity): | 2 per splice cassette |
| Splice holder (splice capacity):: | 1x Crimp/ANT = 12 splices1x Heatshrink = 6 splices |
| Splice holder (splice protection type): | Crimp/ANT (pre-assembled)Heatshrink (included) |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -40 – 80 °C |
| Width: | 482 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | True |
Technical properties
| Adapter material: | plastic |
|---|---|
| Adapters: | LC-Duplex |
| Couplings (ferrule guide): | Ceramic |
| Depth: | 243 mm |
| Depth adjustment: | 40 mm |
| Fibre class: | OS2 acc. to ITU-T G.652.D |
| Fibre type: | Single mode 9/125 |
| Height: | 44 mm |
| Material: | Steel sheet |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Packaging: | EFB-Elektronik Carton |
| Pigtails prepared: | stripped |
| Remark: | vertical |
| Sliding: | sliding |
| Splice cassettes (capacity): | 4 |
| Splice cassettes (number): | 1 |
| Splice cassettes (number of splice holders): | 18 x crimp splice protection holder per splice cassette2 x shrink splice protection holder per splice cassette |
| Splice cassettes (splice holder capacity): | 2 per splice cassette |
| Splice holder (splice capacity):: | 1x Crimp/ANT = 12 splices1x Heatshrink = 6 splices |
| Splice holder (splice protection type): | Crimp/ANT (pre-assembled)Heatshrink (included) |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -40 – 80 °C |
| Width: | 482 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | True |
Variants
| Item no. | Name | Type of connector external | Colour | Pigtail | Suitable for number of couplings/adapters | With number of couplings/adapters | RAL-number | Type of connector interior | Pigtail Coating material | Insertion loss 1625nm | Minimal bendung radius static | Pigtail colour | Pigtail Buffertype | Insertion loss 1550nm | Adapter colour | Pigtail diameter | Minimal bendung radius dynamic | Insertion loss 1310nm | Return loss1625nm | Scope of delivery | Return loss 1310nm | Pigtail length | Pigtail plug colour | Return loss 1550nm | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BA71921L12 | Splice box gy sliding LC OS2 12x fanout pigtails and 6x duplex adapter | LC-Duplex | grey | 12 x LC | 12 | 6 | 7035 | LC-Duplex | LSZH | ≤0.25 dB | 10xD | DIN | Loose-Buffered | ≤0.25 dB | blue | 0.9 mm | 20xD | ≤0.25 dB | ≥50 dB | 19'' splice box extendable with frontpanel and<br>6xadapter, 6xadapter dummy, <br>12xpigtail+Test protocol, 1xsplice cassette+cover+screw, 1xcrimp splice protector holder, 2xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | ≥50 dB | 2 m | blue | ≥50 dB | |
| BA71921L24 | Splice box gy sliding LC OS2 24x fanout pigtails and 12x duplex adapter | LC-Duplex | grey | 24 x LC | 12 | 12 | 7035 | LC-Duplex | LSZH | ≤0.25 dB | 10xD | DIN | Loose-Buffered | ≤0.25 dB | blue | 0.9 mm | 20xD | ≤0.25 dB | ≥50 dB | 19'' splice box extendable with frontpanel and<br>12xadapter, 24xpigtail+Test protocol, 2xsplice cassette+cover+screw, 2xcrimp splice protector holder, 4xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | ≥50 dB | 2 m | blue | ≥50 dB | |
| BA71921L48 | Splice box gy sliding LC OS2 48x fanout pigtails and 24x duplex adapter | LC-Duplex | grey | 48 x LC | 24 | 24 | 7035 | LC-Duplex | LSZH | ≤0.25 dB | 10xD | DIN | Loose-Buffered | ≤0.25 dB | blue | 0.9 mm | 20xD | ≤0.25 dB | ≥50 dB | 19'' splice box extendable with frontpanel and<br>24xadapter, 48xpigtail+Test protocol, 4xsplice cassette+cover+screw, 4xcrimp splice protector holder, 8xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | ≥50 dB | 2 m | blue | ≥50 dB |
Product information for Splice box gy sliding LC OS2 48x fanout pigtails and 24x duplex adapter
The pull-out splice box from EFB-Elektronik is designed for the structured pick-up of splices and the clear management of single-mode fibre optic connections in a 19-inch rack. The 1U version combines a compact design with service-friendly access and is designed for OS2 according to ITU-T G.652.D and 9/125.
• Extendable 1U 19" design – Allows for compact integration into the rack and makes it easy to access the splice level for maintenance and expansion.
• Front panel with 24 LC duplex couplings – Ensures a clearly structured, pre-terminated assembly of the single-mode connectors and keeps the rack front uncluttered.
• 48 prepared LC pigtails with LSZH jacket and 2 m length – Support clean splicing organisation and reduce installation effort in the field.
The splice box has a sheet steel housing in grey according to RAL 7035 and is designed for the clean routing of single-mode lines. The LC duplex couplings with ceramic ferrule guide and the LSZH-coated pigtails support use in professional OS2 installations. Pre-assembled crimp/ANT splice holders and enclosed shrink splice holders enable flexible and traceable splice organisation.
Technical details
• Extendable: extendable
• Fibre class: OS2 according to ITU-T G.652.D
• Couplings: LC-Duplex
• With number of couplings/adapters: 24
• Coupling material: plastic
• Pigtail: 48 x LC
• Pigtails prepared: discontinued
• Number of height units (U): 1U
• Alignment of the couplings/adapters: vertical
• Fibre type: Single-mode 9/125
• Couplings (ferrule guide): Ceramic
• Coupling colour: blue
• Material: sheet steel
• Colour: grey
• Pigtail Buffer Type: Loose-Buffered
• Pigtail Coating Material: LSZH
• Pigtail diameter: 0.9 mm
• Pigtail length: 2 m
• Mounting type: 482.6 mm (19 in) Installation
• Extendable 1U 19" design – Allows for compact integration into the rack and makes it easy to access the splice level for maintenance and expansion.
• Front panel with 24 LC duplex couplings – Ensures a clearly structured, pre-terminated assembly of the single-mode connectors and keeps the rack front uncluttered.
• 48 prepared LC pigtails with LSZH jacket and 2 m length – Support clean splicing organisation and reduce installation effort in the field.
The splice box has a sheet steel housing in grey according to RAL 7035 and is designed for the clean routing of single-mode lines. The LC duplex couplings with ceramic ferrule guide and the LSZH-coated pigtails support use in professional OS2 installations. Pre-assembled crimp/ANT splice holders and enclosed shrink splice holders enable flexible and traceable splice organisation.
Technical details
• Extendable: extendable
• Fibre class: OS2 according to ITU-T G.652.D
• Couplings: LC-Duplex
• With number of couplings/adapters: 24
• Coupling material: plastic
• Pigtail: 48 x LC
• Pigtails prepared: discontinued
• Number of height units (U): 1U
• Alignment of the couplings/adapters: vertical
• Fibre type: Single-mode 9/125
• Couplings (ferrule guide): Ceramic
• Coupling colour: blue
• Material: sheet steel
• Colour: grey
• Pigtail Buffer Type: Loose-Buffered
• Pigtail Coating Material: LSZH
• Pigtail diameter: 0.9 mm
• Pigtail length: 2 m
• Mounting type: 482.6 mm (19 in) Installation
| Adapter material: | plastic |
|---|---|
| Adapters: | LC-Duplex |
| Couplings (ferrule guide): | Ceramic |
| Depth: | 243 mm |
| Depth adjustment: | 40 mm |
| Fibre class: | OS2 acc. to ITU-T G.652.D |
| Fibre type: | Single mode 9/125 |
| Height: | 44 mm |
| Material: | Steel sheet |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Packaging: | EFB-Elektronik Carton |
| Pigtails prepared: | stripped |
| Remark: | vertical |
| Sliding: | sliding |
| Splice cassettes (capacity): | 4 |
| Splice cassettes (number): | 1 |
| Splice cassettes (number of splice holders): | 18 x crimp splice protection holder per splice cassette2 x shrink splice protection holder per splice cassette |
| Splice cassettes (splice holder capacity): | 2 per splice cassette |
| Splice holder (splice capacity):: | 1x Crimp/ANT = 12 splices1x Heatshrink = 6 splices |
| Splice holder (splice protection type): | Crimp/ANT (pre-assembled)Heatshrink (included) |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -40 – 80 °C |
| Width: | 482 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | True |
| Adapter material: | plastic |
|---|---|
| Adapters: | LC-Duplex |
| Couplings (ferrule guide): | Ceramic |
| Depth: | 243 mm |
| Depth adjustment: | 40 mm |
| Fibre class: | OS2 acc. to ITU-T G.652.D |
| Fibre type: | Single mode 9/125 |
| Height: | 44 mm |
| Material: | Steel sheet |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Packaging: | EFB-Elektronik Carton |
| Pigtails prepared: | stripped |
| Remark: | vertical |
| Sliding: | sliding |
| Splice cassettes (capacity): | 4 |
| Splice cassettes (number): | 1 |
| Splice cassettes (number of splice holders): | 18 x crimp splice protection holder per splice cassette2 x shrink splice protection holder per splice cassette |
| Splice cassettes (splice holder capacity): | 2 per splice cassette |
| Splice holder (splice capacity):: | 1x Crimp/ANT = 12 splices1x Heatshrink = 6 splices |
| Splice holder (splice protection type): | Crimp/ANT (pre-assembled)Heatshrink (included) |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -40 – 80 °C |
| Width: | 482 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | True |
Variants
| Item no. | Name | Type of connector external | Colour | Pigtail | Suitable for number of couplings/adapters | With number of couplings/adapters | RAL-number | Type of connector interior | Pigtail Coating material | Insertion loss 1625nm | Minimal bendung radius static | Pigtail colour | Pigtail Buffertype | Insertion loss 1550nm | Adapter colour | Pigtail diameter | Minimal bendung radius dynamic | Insertion loss 1310nm | Return loss1625nm | Scope of delivery | Return loss 1310nm | Pigtail length | Pigtail plug colour | Return loss 1550nm | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BA71921L12 | Splice box gy sliding LC OS2 12x fanout pigtails and 6x duplex adapter | LC-Duplex | grey | 12 x LC | 12 | 6 | 7035 | LC-Duplex | LSZH | ≤0.25 dB | 10xD | DIN | Loose-Buffered | ≤0.25 dB | blue | 0.9 mm | 20xD | ≤0.25 dB | ≥50 dB | 19'' splice box extendable with frontpanel and<br>6xadapter, 6xadapter dummy, <br>12xpigtail+Test protocol, 1xsplice cassette+cover+screw, 1xcrimp splice protector holder, 2xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | ≥50 dB | 2 m | blue | ≥50 dB | |
| BA71921L24 | Splice box gy sliding LC OS2 24x fanout pigtails and 12x duplex adapter | LC-Duplex | grey | 24 x LC | 12 | 12 | 7035 | LC-Duplex | LSZH | ≤0.25 dB | 10xD | DIN | Loose-Buffered | ≤0.25 dB | blue | 0.9 mm | 20xD | ≤0.25 dB | ≥50 dB | 19'' splice box extendable with frontpanel and<br>12xadapter, 24xpigtail+Test protocol, 2xsplice cassette+cover+screw, 2xcrimp splice protector holder, 4xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | ≥50 dB | 2 m | blue | ≥50 dB | |
| BA71921L48 | Splice box gy sliding LC OS2 48x fanout pigtails and 24x duplex adapter | LC-Duplex | grey | 48 x LC | 24 | 24 | 7035 | LC-Duplex | LSZH | ≤0.25 dB | 10xD | DIN | Loose-Buffered | ≤0.25 dB | blue | 0.9 mm | 20xD | ≤0.25 dB | ≥50 dB | 19'' splice box extendable with frontpanel and<br>24xadapter, 48xpigtail+Test protocol, 4xsplice cassette+cover+screw, 4xcrimp splice protector holder, 8xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | ≥50 dB | 2 m | blue | ≥50 dB |
