For standard conformance measurement of structured cabling in buildings
Certification up to 2500 MHz
Support new TIA CAT 8 und ISO Class I and II draft standard
Operating concept Dual Control System (DCS"TM") with two identical hand tools
Autotest in less than 9 Seconds
Professional documentation generator
Impact-resistant housing, impact and shock-proof design, long battery life
Complete glass fiber certification for MM and SM with optional fiber optic measuring adapters
Supports two-wavelength end-to-end measurements for MM and SM glass fibers

General Specifications
Interfaces: Probe Interface, RJ-45 Ethernet, USB host and device, talkset, power jack
Display: 6“ industrial LCD, touch sensitive area on both units
Enclosure: Ruggedized plastic with rubber over-mold, withstands 1.5m drop test on hard surface
Remote unit abilities: View test results, save tests, start autotest
Power supply: AC 100-240V to 12V, 3A power adapter
Input over-voltage protection: Protected against Telco voltages
Battery: Removable and rechargeable Li-Ion
Battery Capacity: >8 hours continuous operation
Internal Storage Capacity: 2000 copper test results with full plot information
External Storage: USB Flash Drive 1 GB in delivery (21 GB max.)
Supported Languages: Chinese, Czech, English, Finnish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish
Calibration period: 1 year
Dimensions: 232 X 126 X 87 mm3 (9.1 X 5.0 X 3.4 inch3) /unit
Weight: Approx. 1.4 kg (3.0 lb) / unit

Environmental
Operating Temparature: 0 to 40 °C
Storage Temperature: -20 to 60 °C
Relative humidity: 10% to 80%

Copper testing
Certification Testing: TIA 568-C.2 CAT 5e, 6, 6A, draft CAT 8
ISO/IEC 11801, EN 50173 Class D,E,EA,F,FA
draft Class I and Class II Permanent link and channel
CAT 5e, 6, 6A, 7, 7A and patch-cord
Autotest time - CAT6A: 9 sec
Autotest time - Class FA: 15 sec
Max cable length for dual ended Autotest: 500m
Insertion Cycles: Channel: 10000 typical
Permanent link: 5000 typical
Advanced Diagnostics: Time-domain fault Locator for RL and NEXT
Measurement Accuracy: Exceeds TIA 1152 Level IIIe, IEC 61935 level IV
Measurement Frequency Range: 1- 2,500 MHz

Fiber Testing - SM
Wavelengths 1310nm, 1550nm
Autotest Time: 6 seconds for dual ended test
Connector Type: SC, LC (optional adapter needed)

Fiber Testing - MM
Wavelengths: 850nm, 1300nm
Autotest Time: 6 seconds for dual ended test
Connector Type: SC

Scope of delivery:
WireXpert Handheld units: 2
Li-Ion Batteries: 2
Stylus with Cords: 2
Display Protection Covers: 2
CAT 6A Permanent Link Interface Adapters: 2
CAT 6A Permanent Link Test Cords: 2
CAT 6A Channel Adapters: 2
USB Thumb Drive incl. Manual and Software: 1
Talk Head Sets: 2
AC Power Adapters: 2
Country Specific Power Cord: 2
Calibration Certificate: 1
Carrying Case: 1
Quick Reference Guide: 1
