19" Network Cabinet set PRO 42U, 800x1200 mm, RAL7035, 4f. fan, power cable +So
Product information for 19" Network Cabinet set PRO 42U, 800x1200 mm, RAL7035, 4f. fan, power cable +So
• 42 height units and baying-compatible design – Offers plenty of installation space and allows flexible expansion to a continuous cabinet row.
• Safety glass front door and steel rear door – Allows visual inspection of the installation while providing robust protection of equipment.
• Load capacity up to 1360 kg and fully pre-assembled frame – Supports heavy loads and reduces on-site assembly.
For use in the 19-inch environment in accordance with DIN 41494, the cabinet is designed with mounting levels at the front and rear. The active ventilation supports thermal operation. The roof and floor each have six pre-punched, break-out openings measuring 450 x 89 mm, which is complemented by the 3U panel with brush on the rear. The front door is designed as a one-piece glass door with 5 mm safety glass. The rear door is made of steel. Interchangeable door hinges and the opening angles of 270 ° at the front and 110 ° at the rear facilitate service and assembly.
Technical details
• Number of doors: 2
• Degree of protection: IP20 according to EN 60529
• Type of ventilation: active
• Air inlet floor: Break-out opening type A (380 x 380 mm), e.g. for filter or cable entry modules
• With earthing: Yes
• With roof panel: Yes
• With front door: Yes
• With side panels: Yes
• With rear door: Yes
• Mounting level: front and rear
• Front door design: one-piece glass door (certified safety glass, glass thickness 5 mm)
• Front door opening angle: 270°
• Rear door opening angle: 110°
• Front door locking: 3-point bar closure with swing handle
• Locking of the rear door: 2-point quarter-turn latch
• Replaceable profile half-cylinder in front door: Yes, in accordance with DIN 18252 (30/10 mm)
• Scope of delivery: 1x cabinet, 1 x brush strip, 1 x cage nut set (pack of 20 pieces), earthing rail and earthing cable, 4 x levelling feet M12, 2 x keys
• Packaging: Delivered in transport packaging on a single-use pallet
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
Technical properties
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
Variants
| Item no. | Name | Number of height units | Front door locking system | Width | Colour | Material rear door | Max. load capacity | Rear door locking system | Depth | With vertical cable management | Material front door | Height | RAL-number | Number of doors | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PRO-4280GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1000 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4282GR.G1SV-SET1 | 19" Network Cabinet set PRO 42U, 800x1200 mm, RAL7035, 4f. fan, power cable +So | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1200 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4288GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1000 kg | 2-point latch locking mechanism | 800 mm | False | Glass | 2063 mm | 7035 | 2 |
Product information for 19" Network Cabinet set PRO 42U, 800x1200 mm, RAL7035, 4f. fan, power cable +So
• 42 height units and baying-compatible design – Offers plenty of installation space and allows flexible expansion to a continuous cabinet row.
• Safety glass front door and steel rear door – Allows visual inspection of the installation while providing robust protection of equipment.
• Load capacity up to 1360 kg and fully pre-assembled frame – Supports heavy loads and reduces on-site assembly.
For use in the 19-inch environment in accordance with DIN 41494, the cabinet is designed with mounting levels at the front and rear. The active ventilation supports thermal operation. The roof and floor each have six pre-punched, break-out openings measuring 450 x 89 mm, which is complemented by the 3U panel with brush on the rear. The front door is designed as a one-piece glass door with 5 mm safety glass. The rear door is made of steel. Interchangeable door hinges and the opening angles of 270 ° at the front and 110 ° at the rear facilitate service and assembly.
Technical details
• Number of doors: 2
• Degree of protection: IP20 according to EN 60529
• Type of ventilation: active
• Air inlet floor: Break-out opening type A (380 x 380 mm), e.g. for filter or cable entry modules
• With earthing: Yes
• With roof panel: Yes
• With front door: Yes
• With side panels: Yes
• With rear door: Yes
• Mounting level: front and rear
• Front door design: one-piece glass door (certified safety glass, glass thickness 5 mm)
• Front door opening angle: 270°
• Rear door opening angle: 110°
• Front door locking: 3-point bar closure with swing handle
• Locking of the rear door: 2-point quarter-turn latch
• Replaceable profile half-cylinder in front door: Yes, in accordance with DIN 18252 (30/10 mm)
• Scope of delivery: 1x cabinet, 1 x brush strip, 1 x cage nut set (pack of 20 pieces), earthing rail and earthing cable, 4 x levelling feet M12, 2 x keys
• Packaging: Delivered in transport packaging on a single-use pallet
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
Variants
| Item no. | Name | Number of height units | Front door locking system | Width | Colour | Material rear door | Max. load capacity | Rear door locking system | Depth | With vertical cable management | Material front door | Height | RAL-number | Number of doors | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PRO-4280GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1000 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4282GR.G1SV-SET1 | 19" Network Cabinet set PRO 42U, 800x1200 mm, RAL7035, 4f. fan, power cable +So | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1200 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4288GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1000 kg | 2-point latch locking mechanism | 800 mm | False | Glass | 2063 mm | 7035 | 2 |
