19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035
Product information for 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035
• Load capacity up to 1,360 kg and fully pre-assembled frame – Provides high reserves for dense assembly and reduces assembly effort on site.
• Baying compatible 19" design with mounting levels at the front and rear – Facilitates modular expansion into a cabinet row and creates flexibility in equipping.
• Front glass door, rear steel door and active ventilation with cable entries in the roof, floor and rear door – Allows visual inspection, robust shielding and clean routing.
The cabinet is suitable for installations with increased space requirements and high cabling requirements. The screwed, completely pre-assembled frame with offset profile rails ensures a stable base. The powder-coated surface in grey is designed for use in 19" environments in accordance with DIN 41494. The front door is made of one-piece safety glass with a glass thickness of 5 mm. A one-piece steel door is used at the rear. Both doors are hinged interchangeably. The design is complemented by a 3-point rod closure at the front, a 2-point quarter-turn latch at the rear door and a replaceable profile half-cylinder at the front.
Technical details
• Number of doors: 2
• Degree of protection: IP20 according to EN 60529
• Type of ventilation: active
• Floor air inlet: Break-out opening type A (380 x 380 mm), e.g. for filter or cable entry modules
• With earthing: Yes
• With roof panel: Yes
• With front door: Yes
• With side panels: Yes
• With rear door: Yes
• Mounting level: front and rear
• Front door design: one-piece glass door (certified safety glass, glass thickness 5 mm)
• Front door opening angle: 270°
• Rear door opening angle: 110°
• Front door locking: 3-point bar closure with swing handle
• Locking of the rear door: 2-point quarter-turn latch
• Replaceable profile half-cylinder in front door: Yes, in accordance with DIN 18252 (30/10 mm)
• Scope of delivery: 1x cabinet, 1 x brush strip, 1 x cage nut set (pack of 20 pieces), earthing rail and earthing cable, 4 x levelling feet M12, 2 x keys
• Packaging: Delivered in transport packaging on a single-use pallet
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
Technical properties
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
Variants
| Item no. | Name | Number of height units | Front door locking system | Width | Colour | Material rear door | Max. load capacity | Rear door locking system | Depth | With vertical cable management | Material front door | Height | RAL-number | Number of doors | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PRO-4280GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1000 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4282GR.G1SV-SET1 | 19" Network Cabinet set PRO 42U, 800x1200 mm, RAL7035, 4f. fan, power cable +So | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1200 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4288GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1000 kg | 2-point latch locking mechanism | 800 mm | False | Glass | 2063 mm | 7035 | 2 |
Product information for 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035
• Load capacity up to 1,360 kg and fully pre-assembled frame – Provides high reserves for dense assembly and reduces assembly effort on site.
• Baying compatible 19" design with mounting levels at the front and rear – Facilitates modular expansion into a cabinet row and creates flexibility in equipping.
• Front glass door, rear steel door and active ventilation with cable entries in the roof, floor and rear door – Allows visual inspection, robust shielding and clean routing.
The cabinet is suitable for installations with increased space requirements and high cabling requirements. The screwed, completely pre-assembled frame with offset profile rails ensures a stable base. The powder-coated surface in grey is designed for use in 19" environments in accordance with DIN 41494. The front door is made of one-piece safety glass with a glass thickness of 5 mm. A one-piece steel door is used at the rear. Both doors are hinged interchangeably. The design is complemented by a 3-point rod closure at the front, a 2-point quarter-turn latch at the rear door and a replaceable profile half-cylinder at the front.
Technical details
• Number of doors: 2
• Degree of protection: IP20 according to EN 60529
• Type of ventilation: active
• Floor air inlet: Break-out opening type A (380 x 380 mm), e.g. for filter or cable entry modules
• With earthing: Yes
• With roof panel: Yes
• With front door: Yes
• With side panels: Yes
• With rear door: Yes
• Mounting level: front and rear
• Front door design: one-piece glass door (certified safety glass, glass thickness 5 mm)
• Front door opening angle: 270°
• Rear door opening angle: 110°
• Front door locking: 3-point bar closure with swing handle
• Locking of the rear door: 2-point quarter-turn latch
• Replaceable profile half-cylinder in front door: Yes, in accordance with DIN 18252 (30/10 mm)
• Scope of delivery: 1x cabinet, 1 x brush strip, 1 x cage nut set (pack of 20 pieces), earthing rail and earthing cable, 4 x levelling feet M12, 2 x keys
• Packaging: Delivered in transport packaging on a single-use pallet
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
| Active air conditioning: | False |
|---|---|
| Air inlet floor: | Breakout opening type A (380 x 380 mm), e.g. for filter or cable entry modules |
| Cabinet Series: | PRO |
| Cable entry rear door: | 3U panel including brush, opening 690 x 67 mm, usable from the bottom or top |
| Cable entry roof/floor: | Roof and base each with 6 pre-cut, breakable openings, all around, each 450 x 89 mm (re-sealable with a 19" 2U blanking plate) |
| Category: | 19" network cabinet according to DIN41494 |
| Degree of protection: | IP20 according to EN60529 |
| Demountable: | True |
| Door hinge reversible front door: | True |
| Door hinge reversible rear door: | True |
| Door opening angle front door: | 270 ° |
| Door opening angle rear door: | 110 ° |
| Frame: | screwed together, completely pre-assembled |
| Material: | Steel |
| Model: | With permanent frame |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front and rear |
| PHC replaceable front door: | True, according to DIN18252 (30/10 mm) |
| PHC replaceable rear door: | False |
| Packaging: | Delivery in transport packaging on a disposable pallet |
| Scope of delivery: | 1x cabinet, 1 x brush strip, 1 x cage nut set (20 pieces per pack), grounding rail and grounding cable, 4 x M12 leveling feet, 2 x keys |
| Stackable: | True |
| Surface finishing: | Powder coating |
| Type of back door: | Steel door 1-part |
| Type of front door: | Glass door 1-part (certified safety glass, glass thickness 5 mm) |
| Type of profile rail: | Crank |
| Type of ventilation: | Active |
| With backside door: | True |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
| With socket: | True |
Variants
| Item no. | Name | Number of height units | Front door locking system | Width | Colour | Material rear door | Max. load capacity | Rear door locking system | Depth | With vertical cable management | Material front door | Height | RAL-number | Number of doors | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PRO-4280GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1000 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4282GR.G1SV-SET1 | 19" Network Cabinet set PRO 42U, 800x1200 mm, RAL7035, 4f. fan, power cable +So | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1360 kg | 2-point latch locking mechanism | 1200 mm | False | Glass | 2063 mm | 7035 | 2 | |
| PRO-4288GR.G1SV-SET1 | 19" Network Cabinet Set PRO 42U, 800x800 mm, RAL7035 | 42 U | 3-point rod locking mechanism with swivel lever | 800 mm | grey | Steel | 1000 kg | 2-point latch locking mechanism | 800 mm | False | Glass | 2063 mm | 7035 | 2 |
