Cat.6A Patchpanel with assembled Adapter
Prices only visible for logged in users
CAT.6A 24-Port Patch-Panel 19" 1U armed with mounting-adapter
Item number:
37598.1
EAN no.:
4049759095451
Product information for CAT.6A 24-Port Patch-Panel 19" 1U armed with mounting-adapter
• Mounting-Adapter: Cat.6A Snap-In 10 Gbit RJ45 jack/RJ45 jack (37521.1)
• Incl. Cable management
• Strain relief via cable tie
• Incl. Cable management
• Strain relief via cable tie
Technical properties
| Bandwidth: | 500 MHz |
|---|---|
| Category: | 6A (TIA) |
| Colour Code: | acc. TIA/EIA 568A/B |
| Connection type: | Keystone |
| Contact Resistance: | 20 mΩ |
| Contact coating: | 50 µ" gold plated |
| Current Rating: | 1.5 A |
| Depth: | 125.0 mm |
| Dielectric Withstanding Voltage: | 1000 V AC 60Hz |
| Electrical strength: | 125 V AC RMS |
| Height: | 44.5 mm |
| Housing material Panel: | Steel |
| Housing material of RJ45 jacks: | PBT |
| Insertion force: | 30 N |
| Insulation Resistance: | 500 MΩ |
| Mating cycles RJ45 jack: | 750 |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| POE Standard: |
POE POE+ |
| Suitable for number of connectors: | 24 |
| Temperature Range (Operation): | -10 – 60 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Transmission: | 10 Gbit |
| Type of connector: | RJ45 8(8) |
| Width: | 483.0 mm |
| screened: | True |
