Mini-Patchpanel STP 8xRJ45 Cat.6, 10“ 1U
Prices only visible for logged in users
Mini-Patchpanel STP 8xRJ45 Cat.6, 10“ 1U, RAL7035, grey
Item number:
37736.8
EAN no.:
4049759186586
Product information for Mini-Patchpanel STP 8xRJ45 Cat.6, 10“ 1U, RAL7035, grey
The high quality of the shielded Cat.6 RJ45 mini patch panel ensures excellent performance for 5 Gigabit Ethernet applications. In addition, the mini patch panel is characterized by its versatile mounting options. It is suitable for installation in a 10 "plane, for attachment to the wall or in conjunction with the DIN rail clamp set (Part No. H83030.1) for DIN rail mounting.
10 "mounting / wall mounting or DIN rail mounting possible, 1U
8 ports
LSA connection strip for installation cable AWG24..AWG22
Color code according to TIA / EIA 568 A / B
Lid with quick release
With earthing terminal
Scope of delivery:
8 cable ties, assembly instructions
4 screws (M6x16mm) and nut
10 "mounting / wall mounting or DIN rail mounting possible, 1U
8 ports
LSA connection strip for installation cable AWG24..AWG22
Color code according to TIA / EIA 568 A / B
Lid with quick release
With earthing terminal
Scope of delivery:
8 cable ties, assembly instructions
4 screws (M6x16mm) and nut
Technical properties
| Bandwidth: | 250 MHz |
|---|---|
| Category: | 6 |
| Colour Code: | acc. TIA/EIA 568A/B |
| Complaint to UL94: | V-0 |
| Connection type: | LSA |
| Contact Resistance: | 100 mΩ |
| Cross section: | AWG 24 - AWG 22 |
| Current Rating: | 1.5 A |
| Depth: | 108.0 mm |
| Dielectric Withstanding Voltage: | 750 V AC 60Hz |
| Durability LSA contacts: | 200 |
| Electrical strength: | 125 V AC RMS |
| Height: | 44.0 mm |
| Housing material LSA-terminal: | PC |
| Housing material Panel: | Steel, 1.5mm |
| Housing material of RJ45 jacks: | PBT |
| Insertion force: | 50 N |
| Insulation Resistance: | 1000 MΩ |
| Material LSA contacts: | Phosphor bronze, tinned |
| Mating cycles RJ45 jack: | 750 |
| Mounting method: | Other |
| Number of height units: | 1 U |
| POE Standard: |
POE POE+ |
| Suitable for number of connectors: | 8 |
| Temperature Range (Operation): | -10 – 60 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Transmission: | 5 Gbit |
| Type of connector: | RJ45 8(8) |
| Width: | 254.6 mm |
| screened: | True |
