Patchpanel STP 24xRJ45 Cat.5e, 19“ 1U
Patchpanel STP 24xRJ45 Cat.5e, 19“ 1U, RAL7035 grey
Item number:
37668.1M
EAN no.:
4049759186364
Product information for Patchpanel STP 24xRJ45 Cat.5e, 19“ 1U, RAL7035 grey
The high quality of the shielded Cat.5e RJ45 patch panel ensures excellent performance for 2.5 Gigabit Ethernet applications.
19" mounting, 1U
24 Ports
LSA connection strip for installation cable AWG24..AWG22
Color code according to TIA / EIA 568 A / B
Lid with clip closure
With earthing terminal
Scope of delivery:
24 cable ties, Instruction manual
19" mounting, 1U
24 Ports
LSA connection strip for installation cable AWG24..AWG22
Color code according to TIA / EIA 568 A / B
Lid with clip closure
With earthing terminal
Scope of delivery:
24 cable ties, Instruction manual
Technical properties
| Bandwidth: | 100 MHz |
|---|---|
| Category: | 5e |
| Colour Code: | acc. TIA/EIA 568A/B |
| Complaint to UL94: | V-0 |
| Connection type: | LSA |
| Contact Resistance: | 100 mΩ |
| Cross section: | AWG 24 - AWG 22 |
| Current Rating: | 1.5 A |
| Depth: | 108.0 mm |
| Dielectric Withstanding Voltage: | 750 V AC 60Hz |
| Durability LSA contacts: | 200 |
| Electrical strength: | 125 V AC RMS |
| Height: | 44.0 mm |
| Housing material LSA-terminal: | PC |
| Housing material Panel: | Steel, 1.5mm |
| Housing material of RJ45 jacks: | PBT |
| Insertion force: | 50 N |
| Insulation Resistance: | 1000 MΩ |
| Material LSA contacts: | Phosphor bronze, tinned |
| Mating cycles RJ45 jack: | 750 |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| POE Standard: |
POE POE+ |
| Suitable for number of connectors: | 24 |
| Temperature Range (Operation): | 0 – 70 °C |
| Temperature Range (Storage): | -40 – 85 °C |
| Transmission: | 2.5 Gbit |
| Type of connector: | RJ45 8(8) |
| Width: | 483.0 mm |
| screened: | True |
