INFRALAN® Patch cord U/UTP Cat.6A, moulded grommet, grey
INFRALAN® RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 2m, grey
Item number:
IPK-6A-U-HFR-GR-0200
EAN no.:
4049759249489
Product information for INFRALAN® RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 2m, grey
The unshielded Cat.6A RJ45 premium patch cable ensures very good characteristics for 10 Gigabit Ethernet applications. The moulded grommet captivates with its slim design and thus simplifies the insertion process in cramped conditions.
Cross section 4 x 2 x AWG24/7
Cast anti-kink grommet with length imprint, slim design
Cross section 4 x 2 x AWG24/7
Cast anti-kink grommet with length imprint, slim design
Technical properties
| AWG-size: | 24/7 |
|---|---|
| Allocation: | acc. TIA/EIA 568B |
| Anti-kink sleeve: | moulded-on |
| Bending radius: | >30 mm |
| Cable construction: | 4x2 |
| Cable shape: | rund |
| Cable type: | U/UTP |
| Cabling standard: | ISO/IEC 11801 |
| Category: | 6A (TIA) |
| Colour anti-kink sleeve: | grey |
| Colour outer sheath: | grey |
| Conductive shield: | No |
| Conductor Material: | Copper |
| Connector: | IEC 60603-7-41 |
| Connector type: | RJ45 standard blue |
| Contacts: | Gold plated |
| Fire retardant version: | acc. IEC60332-1 |
| Halogen free: | True |
| Harmonised Standard: | EN 50575 |
| Jacket material: | LSZH |
| Locking lever: | True |
| Low smoke: | True |
| Mating cycles: | ≥750 |
| Model: | unshielded |
| NVP value: | - % |
| Operating Temperature: | 0 – 60 °C |
| Outer diameter of the cable: | 6.0 mm |
| Pin assignment: | 1:1 |
| Printing: | Cat.6A PREMIUM Patchcord U/UTP 4x2xAWG24/7 ISO/IEC11801 TIA/EIA-568-C.2 ***10Gigabit Ethernet*** |
| Tape width: | 500MHz |
| Test voltage: | 1000 (V DC, 1min) core/core und core/screen |
| Transmission: | 10Gbit |
| Type of connector connection 1: | RJ45 8(8) |
| Type of connector connection 2: | RJ45 8(8) |
| UL approbated: | False |
| UV resistant: | no |
