INFRALAN® U-DQ(ZN)BH OS2 Eca 5000N LSZH black G657A1
INFRALAN® U-DQ(ZN)BH OS2 48E (4x12) Eca 5000N LSZH black 11.2mm G657A1
Item number:
54448.1D-E5
EAN no.:
4049759316358
Product information for INFRALAN® U-DQ(ZN)BH OS2 48E (4x12) Eca 5000N LSZH black 11.2mm G657A1
This universal fiber optic cable is ideal for LAN, MAN and WAN backbones, both indoors and outdoors. It can be laid directly in the ground (in a sand bed) or in pipes and offers effective rodent protection.
The stranded, gel-filled loose tube ensures reliable, structured cabling. With a metal-free, longitudinally watertight construction and a tensile strength of 5.0 kN, it is particularly robust.
The halogen-free, flame-retardant jacket complies with IEC60332-1 and Eurobrand class Eca, which also makes it safe for indoor use. The cable exceeds the requirements of EN50173-1 and ISO/IEC11801, ideal for high-performance networks.
The stranded, gel-filled loose tube ensures reliable, structured cabling. With a metal-free, longitudinally watertight construction and a tensile strength of 5.0 kN, it is particularly robust.
The halogen-free, flame-retardant jacket complies with IEC60332-1 and Eurobrand class Eca, which also makes it safe for indoor use. The cable exceeds the requirements of EN50173-1 and ISO/IEC11801, ideal for high-performance networks.
Technical properties
| Application: | Inside/outside |
|---|---|
| Armouring: | True |
| Blow in: | False |
| Cable metal free: | True |
| Cabling standards: | ISO/IEC 11801 |
| Cabling standards: | EN 50173-1 |
| Colour outer sheath: | schwarz |
| Crush resistance: | 3000 N/dm |
| Fiber marking: | Colour |
| Fibre category: | OS2 G657A1 |
| Fibre type: | Single mode 9/125 |
| Flame retardant: | According to IEC/EN 60332-1-2 |
| Halogen free: | True |
| Jacket material: | LSZH |
| Longitudinal water blocking: | True |
| Low smoke: | True |
| Radial water blocking: | True |
| Temperature Range (Installation): | -20 – 60 °C |
| Temperature Range (Operation): | -40 – 70 °C |
| Temperature Range (Storage): | -30 – 60 °C |
| Type of tube: | Stranded loose tube |
| UV resistant: | True |
| With rodent protection: | True |
Variants
| Item no. | Name | Category | Tensile force max. | Number of fibers | CPR-Class | Cable Ø | Number of fibres per tube | Construct | Outer diameter approx. | Fire load | VDE-Name | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 54448.1D-E5 | INFRALAN® U-DQ(ZN)BH OS2 48E (4x12) Eca 5000N LSZH black 11.2mm G657A1 | OS2 | 5000 N | 48 | Eca | 11.2 mm | 12 | (4x12) | 11.2 mm | 2725 MJ/km | U-DQ(ZN)BH 4x12E9/125 | 107 kg/km | |
| 54496.1D-E5 | INFRALAN® U-DQ(ZN)BH OS2 96E (8x12) Eca 5000N LSZH black 12.8mm G657A1 | OS2 | 5000 N | 96 | Eca | 12.8 mm | 12 | (8x12) | 12.8 mm | 3299 MJ/km | U-DQ(ZN)BH 8x12E9/125 | 140 kg/km |
