Partially Assembled Splice Boxes LC-Duplex plastic adapter, non-sliding version, OM3
Splicebox bk partially assembled LC OM3 not extendable 12 Adapter
Item number:
B60901TS.12OM3
EAN no.:
4049759172565
Product information for Splicebox bk partially assembled LC OM3 not extendable 12 Adapter
Partly assembled splice box with adapters
per 12 adapters 1 splice cassette with 1 splice holder
suitable up to 4 splice cassettes
metal housing not sliding unit
front panel screwed
plastic adapters
cable entries at the rear
per 12 adapters 1 splice cassette with 1 splice holder
suitable up to 4 splice cassettes
metal housing not sliding unit
front panel screwed
plastic adapters
cable entries at the rear
Technical properties
| Adapters: | LC |
|---|---|
| Depth: | 244.0 mm |
| Fibre class: | OM3 |
| Fibre type: | Multi mode 50/125 |
| Height: | 44.5 mm |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Sliding: | non sliding version |
| Width: | 483.0 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | False |
Variants
| Item no. | Name | Suitable for number of couplings/adapters | Type of connector external | Colour | With number of couplings/adapters | RAL-Nummer | Steckverbindertyp innen | Kupplungsfarbe | |
|---|---|---|---|---|---|---|---|---|---|
| B60901.6OM3 | Splicebox partially assembled LC OM3 not extendable 6 Adapter | 12 | LC-Duplex | grey | 6 | 7035 | LC-Duplex | aqua | |
| B60901.12OM3 | Splicebox partially assembled LC OM3 not extendable 12 Adapter | 12 | LC-Duplex | grey | 12 | 7035 | LC-Duplex | aqua | |
| B60901.24OM3 | Splicebox partially assembled LC OM3 not extendable 24 Adapter | 24 | LC-Duplex | grey | 24 | 7035 | LC-Duplex | aqua | |
| B60901TS.6OM3 | Splicebox bk partially assembled LC OM3 not extendable 6 Adapter | 12 | LC-Duplex | black | 6 | 9005 | LC-Duplex | aqua | |
| B60901TS.12OM3 | Splicebox bk partially assembled LC OM3 not extendable 12 Adapter | 12 | LC-Duplex | black | 12 | 9005 | LC-Duplex | aqua |
