GEP-2681, 26-Port L3 Lite Managed Gigabit Ethernet PoE+ Switch, 2x SFP/RJ45 Combo
26-Port L3 Lite Managed Gigabit PoE+ Switch, 24x PoE+, 185W, 2 x1G SFP/RJ45
Item number:
GEP-2681
EAN no.:
4015867198964
Product information for 26-Port L3 Lite Managed Gigabit PoE+ Switch, 24x PoE+, 185W, 2 x1G SFP/RJ45
24 PoE+ Gigabit Ethernet Ports + 2 Gigabit Ethernet SFP/RJ45 Combo Slots
SFP Slots supports MiniGBICs for Gigabit 1000Base-X
IEEE-802.3af / at PoE compliance with PoE detection
PoE+ up to 30W pro Port
Max. PoE Power: 185W
QoS, VLAN, LACP, Port mirrowing, Autonegotiation and Auto MDI/MDIX
Management: SNMP, WEB, RMON
19“ Mounting brackets included
Metal housing (L x W x D): 442 x 211 x 44 mm
SFP Slots supports MiniGBICs for Gigabit 1000Base-X
IEEE-802.3af / at PoE compliance with PoE detection
PoE+ up to 30W pro Port
Max. PoE Power: 185W
QoS, VLAN, LACP, Port mirrowing, Autonegotiation and Auto MDI/MDIX
Management: SNMP, WEB, RMON
19“ Mounting brackets included
Metal housing (L x W x D): 442 x 211 x 44 mm
Technical properties
| 10 Gigabit Ethernet: | False |
|---|---|
| Depth: | 211.0 mm |
| Ethernet: | True |
| Fast Ethernet: | True |
| Gigabit Ethernet: | True |
| Height: | 44.0 mm |
| Layer 2: | True |
| Layer 3: | True |
| Manageable: | True |
| Management: | L3 lite |
| Manufacturer: | LevelOne |
| Max. PoE per Port: | 30 W |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of combination-ports RJ45/Mini GBIC: | 2 |
| Number of ports 10/100/1000 Mbps RJ45: | 24 |
| Number of ports PoE: | 24 |
| PoE Port: | 24 |
| Power over Ethernet (PoE): | 802.3 at (PoE+) |
| Width: | 442.0 mm |
Safety instructions
Warning: Danger of electric shocks and short circuits! Ensure proper earthing to avoid electric shocks. Avoid overloading as this can lead to overheating and short circuits. Check that the housing is undamaged and that there are no exposed contacts or bare wires. Ensure that all electrical connections are made correctly and that the ambient conditions comply with the technical specifications. Always keep a sufficient distance from live devices and avoid misuse.
