INFRALAN® SC Adapter in plastic housing
INFRALAN® adapter SC Duplex OM4 erica violet
Item number:
IKL-SCDU-MM-K-EV
EAN no.:
4049759194291
Product information for INFRALAN® adapter SC Duplex OM4 erica violet
The INFRALAN® SC Duplex adapter in a coloured plastic housing according to the fiber class
Conform to DIN EN 61754-4
Mounting options via clips or sheet metal screws ST2.5
Conform to DIN EN 61754-4
Mounting options via clips or sheet metal screws ST2.5
Technical properties
| Accessories: | Self-Tapping Screw |
|---|---|
| Conform to Standard: | IEC61754-4 |
| Construction type: | SC Duplex |
| Height: | 9.4 mm |
| Length: | 27.4 mm |
| Material housing: | Plastic |
| Material sleeve: | Ceramics |
| Operating Temperature: | -40 – 75 °C |
| Storage Temperature: | -40 – 85 °C |
| Type of connector connection 1: | SC duplex |
| Type of connector connection 2: | SC duplex |
| Type of fastening: | Screw/snap in |
| Width: | 34.7 mm |
Manufacturer information
EFB-Elektronik GmbH
Striegauer Str. 1
33719 Bielefeld
info@efb-elektronik.de
https://www.efb-elektronik.de
