SC / APC Singlemode
SM Attenuators SC/APC 8 dB Return Loss 60 dB, SM
Item number:
53361.8
EAN no.:
4049759171803
Product information for SM Attenuators SC/APC 8 dB Return Loss 60 dB, SM
Attenuators are used to increase the attenuation of fiber optic lines. This can be necessary at short distances to prevent overmodulation of the receiver. SPC = Return Loss max. 45 dB
APC = Return Loss max. 60 dB
Suitable for CWDM !
Attenuation in dB:
1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 10 - 15 - 20
APC = Return Loss max. 60 dB
Suitable for CWDM !
Attenuation in dB:
1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 10 - 15 - 20
Technical properties
| Conform to Standard: | IEC61754-4 |
|---|---|
| Dust cover: | True |
| Height: | 9.3 mm |
| Internal Shutter: | False |
| Length: | 32.8 mm |
| Material housing: | metal |
| Material sleeve: | ceramic |
| Operating Temperature: | -20 – 75 °C |
| Storage Temperature: | -40 – 75 °C |
| Type of connector connection 1: | SC |
| Type of connector connection 2: | SC |
| Type of housing: | flangeless |
| Width: | 12.7 mm |
