19“ 1U Socket Strip 7 x CEE 7/3 with Surge Protection
19“ 1U Socket Strip 7 x CEE 7/3 with Surge Protection, in Alu Profile, Black
Item number:
EK631DE.3
EAN no.:
4049759203962
Product information for 19“ 1U Socket Strip 7 x CEE 7/3 with Surge Protection, in Alu Profile, Black
19" 1U socket strip in aluminium profile
Outlets 7 x CEE 7/3
With surge protection
Outlets turned 45°
With increased personal protection against electric shock
Cable 2 m H03VV-F 3G 1.5 mm² with angled CEE7/7 plug
Colour black
Certifications CE, RoHS
Note: after an overvoltage event, the strip is still suitable for power supply without surge protection, i.e. the surge protection is not multifunctional
Outlets 7 x CEE 7/3
With surge protection
Outlets turned 45°
With increased personal protection against electric shock
Cable 2 m H03VV-F 3G 1.5 mm² with angled CEE7/7 plug
Colour black
Certifications CE, RoHS
Note: after an overvoltage event, the strip is still suitable for power supply without surge protection, i.e. the surge protection is not multifunctional
Technical properties
| Angle rotated central insert: | 45 ° |
|---|---|
| Core cross section: | 1.50 mm² |
| Degree of protection: | IP20 |
| Halogen free: | No |
| Housing shape: | Rectangular |
| Length of power cord: | 2.0 m |
| Mains filter: | False |
| Material: | Metal |
| Material quality: | Aluminium |
| Nominal current: | 16 A |
| Over voltage protection: | True |
| Residual current circuit breaker (RCCB): | False |
| Rotated central insert: | True |
| Surface finishing: | matt |
| Surface treatment: | Anodised |
| Transparent: | False |
| With cover lid: | False |
Variants
| Item no. | Name | With on/off switch | Color | Number of socket outlets with protective contact (CEE7/3) | RAL-number (similar) | |
|---|---|---|---|---|---|---|
| EK631DE.3GR | 19“ 1U Socket Strip 7 x CEE 7/3 with Surge Protection, in Alu Profile, Grey | False | grey | 7 | 7035 | |
| EK631DE.3 | 19“ 1U Socket Strip 7 x CEE 7/3 with Surge Protection, in Alu Profile, Black | False | black | 7 | 9005 |
Safety instructions
Do not block any ventilation openings to prevent components from overheating. Do not operate the appliance beyond the permissible connected loads to prevent overloading and excessive heat generation. Ensure that the device does not overheat during operation.
Manufacturer information
EFB-Elektronik GmbH
Striegauer Straße 1
33719 Bielefeld
info@efb-elektronik.de
https://www.efb-elektronik.de/kontakt
