Extension Cable Dual-Lock C14 - C13, Red
Extension Cable C14 - C13, Dual Lock, Red, 3 m
Item number:
EK620RT.3
EAN no.:
5056313247255
Product information for Extension Cable C14 - C13, Dual Lock, Red, 3 m
With „Dual-Lock“: prevents accidentally removing of the C13 jack from devices
After connecting, the C13 jack only can be released after sliding back the red latch
10 A / 250 V VDE tested (optional: orange, blue, grey, white)
After connecting, the C13 jack only can be released after sliding back the red latch
10 A / 250 V VDE tested (optional: orange, blue, grey, white)
Technical properties
| (Halogenfree): | False |
|---|---|
| Colour outer sheath: | schwarz |
| Connection 1: | Kaltgerätestecker |
| Connection 2: | Kaltgerätebuchse gerade |
| Jacket material: | Polyvinylchlorid (PVC) |
| Nominal voltage: | 250 V |
| Number of cores: | 3 |
| Oil resistant (acc. EN 60811-2-1): | Nein |
| Oil resistant (according to EN 60811-404): | False |
| Protective conductor: | Ja |
| Spiralized cable: | Nein |
| Temperature resistance: | 5 – 70 °C |
| With cord switch: | Nein |
Variants
| Item no. | Name | Nominal current | With protective conductor | Colour outer sheath | Degree of protection | Nominal voltage | Length | Nominal cross section conductor | Outer diameter approx. | |
|---|---|---|---|---|---|---|---|---|---|---|
| EK620RT.0,5 | Extension Cable C14 - C13, Dual Lock, Red, 0.5 m | 10 A | Ja | rot | IP20 | – 250 V | 0.5 m | 1.04 (AWG17) mm² | 8.0 mm | |
| EK620RT.1 | Extension Cable C14 - C13, Dual Lock, Red, 1 m | 10 A | Ja | rot | IP20 | – 250 V | 1,0 m | 1.04 (AWG17) mm² | 8.0 mm | |
| EK620RT.2 | Extension Cable C14 - C13, Dual Lock, Red, 2 m | 10 A | Ja | rot | IP20 | – 250 V | 2.0 m | 1.04 (AWG17) mm² | 8.0 mm | |
| EK620RT.3 | Extension Cable C14 - C13, Dual Lock, Red, 3 m | 10 A | Ja | rot | IP20 | – 250 V | 3.0 m | 1.04 (AWG17) mm² | 8.0 mm |
Manufacturer information
EFB-Elektronik GmbH
Striegauer Straße 1
33719 Bielefeld
info@efb-elektronik.de
https://www.efb-elektronik.de/kontakt
