Power Cable CEE7/7 90° - C13 180° with IEC Lock+, black
Prices only visible for logged in users
Power Cable CEE7/7 90° - C13 180°, Black, 2.0 m, 3 x 1.00 mm², IEC Lock+
Item number:
EK603SW.2
EAN no.:
5055287012500
Product information for Power Cable CEE7/7 90° - C13 180°, Black, 2.0 m, 3 x 1.00 mm², IEC Lock+
With „IEC Lock+“: prevents accidentally removing of the C13 jack from devices
After connecting, the C13 jack only can be released after sliding back the red latch
10 A / 250 V VDE tested (optional: orange, blue, grey, white)
Suitable for Germany, Belgium, France and further
Other types on request: UK, USA/NEMA, Switzerland, open end
After connecting, the C13 jack only can be released after sliding back the red latch
10 A / 250 V VDE tested (optional: orange, blue, grey, white)
Suitable for Germany, Belgium, France and further
Other types on request: UK, USA/NEMA, Switzerland, open end
Technical properties
Colour outer sheath: | black |
---|---|
Connection 1: | Socket outlet with protective contact, right-angled |
Connection 2: | Cold device plug straight, female |
Halogen free: | False |
Jacket Material: | Polyvinyl chloride (PVC) |
Nominal voltage: | 250 V |
Number of cores: | 3 |
Oil resistant (acc. EN 60811-2-1): | False |
Oil resistant (according to EN 60811-404): | False |
Protective conductor: | True |
Spiralized cable: | False |
Temperature resistance: | 0 – 70 °C |
With cord switch: | False |
Variants
Item no. | Name | Colour outer sheath | Length | Leiternennquerschnitt | Außendurchmesser ca. | |
---|---|---|---|---|---|---|
EK603SW.1 | Power Cable CEE7/7 90° - C13 180°, Black, 1.0 m, 3 x 1.00 mm², IEC Lock+ | black | 1.0 m | 1,00 mm² | 7,1 mm | |
EK603SW.2 | Power Cable CEE7/7 90° - C13 180°, Black, 2.0 m, 3 x 1.00 mm², IEC Lock+ | black | 2.0 m | 1,00 mm² | 7,1 mm |
