Name: Splicebox partially assembled LC OM4 extendable 6 Adapter
Brand: EFB-Elektronik
SKU: B61901.6OM4
Availability: InStock

Partially Assembled Splice Boxes LC-Duplex plastic adapter, sliding version, OM4

Splicebox partially assembled LC OM4 extendable 6 Adapter

Item number: B61901.6OM4

EAN no.: 4049759173203

Color

Suitable for number of couplings/adapters

Type of connector external

With number of couplings/adapters

Please log in to view and order prices.

Get notified when the product is back in stock:

Piece

Please enable JavaScript

You need JavaScript to submit this form because of the CAPTCHA verification.

Description

Product information for Splicebox partially assembled LC OM4 extendable 6 Adapter

Partly assembled splice box with adapters
per 12 adapters 1 splice cassette with 1 splice holder
suitable up to 4 splice cassettes
metal housing sliding unit
front panel screwed
plastic adapters
cable entries at the rear

Technical properties

Adapters:	LC
Depth:	244.0 mm
Extendable:	sliding version
Fibre class:	OM4
Fibre type:	Multi mode 50/125
Height:	44.5 mm
Mounting method:	482.6 mm (19 inch) mounting
Number of height units:	1 U
Width:	483.0 mm
With Pigtail:	False
With front plate:	True
With housing:	True

Variants

Item no.	Name	With number of couplings/adapters	Type of connector external	Color	Suitable for number of couplings/adapters	RAL-number	Type of connector interior	Adapter colour
B61901.4OM4	Splicebox partially assembled LC OM4 extendable 4 Adapter	4	LC-Duplex	grey	12	7035	LC-Duplex	violet	Select variants
B61901.6OM4	Splicebox partially assembled LC OM4 extendable 6 Adapter	6	LC-Duplex	grey	12	7035	LC-Duplex	violet	Select variants
B61901.12OM4	Splicebox partially assembled LC OM4 extendable 12 Adapter	12	LC-Duplex	grey	12	7035	LC-Duplex	violet	Select variants
B61901.24OM4	Splicebox partially assembled LC OM4 extendable 24 Adapter	24	LC-Duplex	grey	24	7035	LC-Duplex	violet	Select variants
