Splicebox sliding unit with LC-Duplex plastic adapter and pigtails, OS2
Splicebox bk LC 9/125µ OS2 extendable 48 Pigtails/24 Adapter
Item number:
B71921TS.48
EAN no.:
4049759139711
Product information for Splicebox bk LC 9/125µ OS2 extendable 48 Pigtails/24 Adapter
completely assembled splice box with adapters and coloured pigtails
metal housing depth adjustable
cable entries at the rear, incl. 1 x PG16
6 x self adhesive fiber tray
Special assembly possible at short notice!
metal housing depth adjustable
cable entries at the rear, incl. 1 x PG16
6 x self adhesive fiber tray
Special assembly possible at short notice!
Technical properties
| Adapter material: | Plastic adapter |
|---|---|
| Adapters: | LC |
| Depth: | 244.0 mm |
| Fibre class: | OS2 acc. to ITU-T G.652.D |
| Fibre type: | Single mode 9/125 |
| Height: | 44.5 mm |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Pigtails prepared: | not stripped |
| Sliding: | sliding version |
| Width: | 483.0 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | True |
Variants
| Item no. | Name | Type of connector external | Suitable for number of couplings/adapters | Colour | With number of couplings/adapters | Pigtail | RAL-Nummer | Steckverbindertyp innen | Kupplungsfarbe | |
|---|---|---|---|---|---|---|---|---|---|---|
| B71920.12 | Splicebox LC-APC 9/125µ OS2 extendable 12 Pigtails/ 6 Adapter | LC-Duplex | 12 | grey | 6 | 12 x LC-APC | 7035 | LC-Duplex | grün | |
| B71920.24 | Splicebox LC-APC 9/125µ OS2 extendable 24 Pigtails/12 Adapter | LC-Duplex | 12 | grey | 12 | 24 x LC-APC | 7035 | LC-Duplex | grün | |
| B71920.48 | Splicebox LC-APC 9/125µ OS2 extendable 48 Pigtails/24 Adapter | LC-Duplex | 24 | grey | 24 | 48 x LC-APC | 7035 | LC-Duplex | grün | |
| B71921.12 | Splicebox LC 9/125µ OS2 extendable 12 Pigtails/6 Aapters | LC-Duplex | 12 | grey | 6 | 12 x LC | 7035 | LC-Duplex | blau | |
| B71921.24 | Splicebox LC 9/125µ OS2 exentable 24 Pigtails/12 Adapter | LC-Duplex | 12 | grey | 12 | 24 x LC | 7035 | LC-Duplex | blau | |
| B71921.48 | Splicebox LC 9/125µ s. OS2 extendable 48 Pigtails/24 Adapter | LC-Duplex | 24 | grey | 24 | 48 x LC | 7035 | LC-Duplex | blau | |
| B71921TS.12 | Splicebox bk LC 9/125µ OS2 extendable 12 Pigtails/6 Adapter | LC-Duplex | 12 | black | 6 | 12 x LC | 9005 | LC-Duplex | blau | |
| B71921TS.24 | Splicebox bk LC 9/125µ OS2 extendable 24 Pigtails/12 Adapter | LC-Duplex | 12 | black | 12 | 24 x LC | 9005 | LC-Duplex | blau | |
| B71921TS.48 | Splicebox bk LC 9/125µ OS2 extendable 48 Pigtails/24 Adapter | LC-Duplex | 24 | black | 24 | 48 x LC | 9005 | LC-Duplex | blau |
