INFRALAN® Cat.7A 1200 AWG22, S/FTP 4P CPR B2ca orange RAL 2003
Prices only visible for logged in users
INFRALAN® Cat.7A 1200 AWG22, S/FTP 4P CPR B2ca orange RAL 2003
Item number:
MK7100.1-CPR
EAN no.:
4049759180980
Product information for INFRALAN® Cat.7A 1200 AWG22, S/FTP 4P CPR B2ca orange RAL 2003
The Delta certified INFRALAN® installation cable MK7100.x-CPR is constructed for transmissions up to 1200 MHz and exceeds with the electrical transmission properties the requirements of the category 7A. Suitable for structured cabling of Class E, EA, F and FA according to ISO/IEC 11801 (AMD 2:2009) resp. EN 50173-1 (2009). The twisted pairs are protected against interferences with a shielding foil (PiMF) and a total shielding. This excellent protection also prevents the radiation of signals out of the cables. The shielding ensures the compliance of emitted interferences according to class B EN 55022 and the interference resistance according to EN 55024. The stranding of the twisted pairs is optimized so that the delay skew between the pairs at the greatest possible uncoupling (crosstalk) is minimun. With this cable transmission rates up to 10 GBit according to IEEE 802.3 are possible.
Technical properties
| AWG-size: | 22/1 |
|---|---|
| Bending radius (dynamic): | 8 x OD |
| Bending radius (static): | 4 x OD |
| Cable: | IEC 61156-5 |
| Cable Construction: | S/FTP |
| Cabling standards: |
EN 50173-1 EN 50288 ISO/IEC 11801 |
| Category: | 7A |
| Characteristic impedance: | 100 ± 15 Ohm |
| Conductor category: | Class 1 = solid |
| Conductor material: | Cu, tinned |
| Core identification: | Colour |
| Core insulation: | foam-skin PE |
| Coupling attenuation: | 90 dB |
| Coupling attenuation Type: | Type 1 |
| Diameter conductor: | 0.62 mm |
| Euro class: | B2ca |
| Flame retardant: | acc. EN 60332-1 |
| Halogen free: | acc. EN 60754-1/2 |
| Halogen free (acc. EN 50267-2-2): | False |
| Halogen free (according to EN 60754-1/2): | True |
| Harmonised Standard: | EN 50575 |
| Installation standard: | EN 50174 |
| Jacket Material: | FRNC-B |
| Loop resistance: | 143.4 Ohm/km |
| Low smoke: | acc. EN 61034-2 |
| Low smoke (according to EN 61034-2): | True |
| Max. Freuqency: | 1200 MHz |
| NVP value: | 78 % |
| Operating temperature, storage: | 0 – 50 °C |
| Permitted cable outer temperature after assembling without vibration: | -20 – 60 °C |
| Permitted cable outer temperature during assembling/handling: | -20 – 50 °C |
| PoE: |
acc. to IEEE802.3af PoE acc. to IEEE802.3at PoE+ acc. to IEEE802.3bt 4PPoE |
| Resistance unbalance: | 3 % |
| Screen over stranding: | braiding |
| Screen over stranding element: | Foil |
| Separation class acc. EN50174-2: | D |
| Stranding element: | Pairs |
| Test voltage DC, 1 min: | 1000 V |
| Transmission standards: | IEEE 802.3 10Mbit to 10Gbit |
| UV resistance: | no |
Variants
| Item no. | Name | Colour outer sheath | RAL colour | Length | Number of cores | Type | Cu-Zahl | Max. Zugkraft | Außendurchmesser ca. | Brandlast | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MK7100.1-CPR | INFRALAN® Cat.7A 1200 AWG22, S/FTP 4P CPR B2ca orange RAL 2003 | orange | RAL2003 | 1.0 m | 8 | simplex | 3,62 kg/100m | 100 N | 8,4 mm | 640 MJ/km | |
| MK7100.100-CPR | INFRALAN® Cat.7A 1200 AWG22, S/FTP 4P CPR B2ca orange RAL 2003, 100m | orange | RAL2003 | 100.0 m | 8 | simplex | 3,62 kg/100m | 100 N | 8,4 mm | 640 MJ/km | |
| MK7100DX.500-CPR | INFRALAN® Cat.7A 1200 AWG22, S/FTP 2x4P CPR B2ca orange RAL 2003 | orange | RAL2003 | 500.0 m | 2x8 | duplex | 7,24 kg/100m | 100 N | 8,4 x16,8 mm | 1100 MJ/km |
