Splicebox sliding unit, with ST metal adapter and pigtails, OS2
Splicebox ST 9/125µ OS2 extendable 24 Pigtails/24 Adapter
Item number:
B71023.24
EAN no.:
4049759075033
Product information for Splicebox ST 9/125µ OS2 extendable 24 Pigtails/24 Adapter
completely assembled splice box with adapters
and coloured pigtails
metal housing depth adjustable
cable entries at the rear, incl. 1 x PG16
6 x self adhesive fiber tray
Special assembly possible at short notice!
and coloured pigtails
metal housing depth adjustable
cable entries at the rear, incl. 1 x PG16
6 x self adhesive fiber tray
Special assembly possible at short notice!
Technical properties
| Adapter material: | Metall adapter |
|---|---|
| Adapters: | ST |
| Depth: | 244.0 mm |
| Extendable: | sliding version |
| Fibre class: | OS2 acc. to ITU-T G.652.D |
| Fibre type: | Single mode 9/125 |
| Height: | 44.5 mm |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Pigtails prepared: | not stripped |
| Width: | 483.0 mm |
| With Pigtail: | True |
| With front plate: | True |
| With housing: | True |
Variants
| Item no. | Name | Type of connector external | Color | Suitable for number of couplings/adapters | With number of couplings/adapters | Pigtail | RAL-number | Type of connector interior | Adapter colour | |
|---|---|---|---|---|---|---|---|---|---|---|
| B71023.6 | Splicebox ST 9/125µ OS2 extendable 6 Pigtails/6 Adapter | ST | grey | 12 | 6 | 6 x ST | 7035 | ST | metal | |
| B71023.12 | Splicebox ST 9/125µ OS2 extendable 12 Pigtails/12 Adapter | ST | grey | 12 | 12 | 12 x ST | 7035 | ST | metal | |
| B71023.24 | Splicebox ST 9/125µ OS2 extendable 24 Pigtails/24 Adapter | ST | grey | 24 | 24 | 24 x ST | 7035 | ST | metal |
